Catrike Dumont eCat
Catrike Dumont eCat
Share
All the comfort and performance of the standard Dumont with the added spark of the latest in electric assist systems from industry leader Bosch. The result is a Dumont with the perfect combination of maximum efficiency, comfort and riding enjoyment. The efficient and versatile Active Line Plus (Class 1) electric-assist drive mated to a 1 x 11 drivetrain (11 - 42 cassette / 44 tooth chainring) provides dynamic performance – guaranteeing an authentic riding sensation with minimal pedaling resistance. It delivers active and sporty acceleration even at low cadences, offering powerful assistance as soon as you step on the pedals. In addition, the system’s multi-sensor technology and fast information processing ensure optimum interaction between you and your eCAT. The Dumont eCAT is made with Bosch components and meets or exceeds all current safety standards and is UL2849 certified.
The Bosch Active Line Plus electric-assist system features four levels of power assistance: Eco - 40%, Tour - 100%, Sport - 180% and Turbo - 270%. Each level also features a maximum drive torque to ensure smooth, gentle acceleration. The Bosch Active Line Plus delivers assistance up to 20 mph and a cadence of 105. Built for derailleur based drivetrains, it features gear shift detection to provide seamless power through the full range of gears.
The Dumont eCAT comes stock with Catrike’s new SUPERNOVA Light System. Powered directly by your eCAT, SUPERNOVA is at the forefront of award-winning design and technology for bicycle safety lighting systems. The eCAT light system includes the SUPERNOVA MINI 2 headlight and TL3 PRO taillight to help keep you visible day and night without charging separate batteries.
The Catrike Dumont ships in 1-2 weeks after we receive the order.
We charge a flat rate of $369 for shipping via freight in most of the Continental US. We do not ship Catrikes outside of the US. There are few zip codes in the US that are more expensive - we will reach out to discuss if this is an issue. It’s usually the very rural locations.
The bike comes 100% fully assembled. We require that all shipped Catrikes are ordered with a boom adjust kit so you just adjust the boom to the proper length, adjust the seat and handlebars to your liking and go for a ride! If you order additional parts with the bike, our website may charge you additional shipping. When we receive the order, we will refund that amount.
A final note about ordering bikes on our website: We will always call you after you place your order to discuss your build, make sure all of the options are correct and ensure that it is the right bike for you. If we need to make changes, additions or cancellations, we will happily do that - we want to make sure you are happy with your new bike. We will NEVER just ship out a bike without a conversation.
Frame & Geometry
Folded Length 45.25 in
Folded Width 32.5 in
Folded Height 25 in
Total Length** 82 in
Total Width 32.5 in
Total Height 28 in
Wheel Base 45.5 in
Wheel Track 29.5 in
Seat Angle 42-49 deg
Weight* 60 lb
Seat Height 10 in
Seat Width 14 in
BB Height** 16.5 in
Ground Clearance 4 in
Height w/ Seat Folded 26.5 in
Turning Circle 18 ft
Turning Radius 9 ft
Rider Weight Limit 275 lbs
Rider X-Seam Range 39-46 in (+5” w/ XL)
Front Suspension Travel 0.5 in
Rear Suspension Travel 2 in
Components
Brakes Avid BB7 Disc Brakes
Brake Levers Catrike Locking Brake Levers
Rear Derailleur SRAM Apex 11 Speed
Shifters SRAM 500 TT Bar End Shifter
Crankset FSA Alloy Crank
Chainring 44-tooth
Chain Guard FSA Guard
Cassette SRAM 11/42 11 Speed
Chain KMC
Idler T-Cycle Sport Power Idler 15T
Headsets FSA Zero Stack
Front Tires 406 Schwalbe Marathon Racer
Rear Tire 559 Schwalbe Marathon Racer
Standard Features
Padded seat
Ergonomic adjustable seat back
Roller wheels for rolling when folded
Padded wrist rests
Rear Fender
Flag Mount & Flag
Mirrycle Rear View Mirror
Multi Purpose Clipless Pedals
Computer Sensor Mount
No Brake Steer
Self Centering
Ackermann Steering Compensation
Structural Front Boom
Quick-Release Indexing Boom Clamp
Aluminum Rod Ends
Low Friction PTFE Flared Chain Tube
12x142 Thru Axle
